16pin OBDII Passthru Cable with Power Break Out and IP68 Rating for Heavy-Duty Automotive Wiring Harness
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | Edgarcn & EdgarWireHarness |
| Certification: | IATF16949 TS16949 UL |
| Model Number: | J1939 & J1962 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10000 |
|---|---|
| Price: | $1.40-1.50 |
|
Detail Information |
|||
| Connector Type: | Deutsch J1939 HD-16-9-1939S-P080 HD-10-9-1939P-P080 | Pin Count: | 2 Pin |
|---|---|---|---|
| Wire Type: | UL 1007 18# And 16# | Contact Retention: | 20 LBS |
| Crimp Tensile: | >20 LBS (18#), >25 LBS (16#) | Operating Temperature: | -40℃ To +125℃ |
| Vibration Resistance: | 20 G's At 10-2000Hz For 2 Hours | IP Rating: | IP68 |
| Waterproof Depth: | 1.2 Meter For 24 Hours | Terminal Type: | 1060-16-0122 |
| Failure Model: | Wire Damage, Grommet Broken | Material: | Silicone Rubber Sealed, Thermoplastic |
| Connector Series: | EDG-HD | Color Options: | Red, Black, Blue, Green |
| Custom Length: | Yes | ||
| Highlight: | 16pin OBDII Passthru Cable,IP68 Rating Automotive Wiring Harness,Power Break Out Diagnostic Connector Cable |
||
Product Description
The EDG-HD series is an environmentally sealed silicone rubber thermoplastic cylindrical connector designed for fast, easy, trouble-free assembly in heavy-duty diagnostic applications including trucks, buses, cross-country vehicles, cranes, and forklifts. When mated, the contacts are protected from water, dust, oils, fuel, road salt, grease, mud, and other contaminants.
- Operating temperature range: -40℃ to +125℃ (no cracking, chipping, or leaking after 20 test cycles)
- Withstands 20 G's sinusoidal vibration at 10-2000Hz for 2 hours in three mutually perpendicular planes with no mechanical damage
- IP68 rated - waterproof with immersion under 1.2 meters of water for 24 hours
| Terminal Type | Wire Type | Contact Retention | Ref Crimp Tensile | Failure Model |
|---|---|---|---|---|
| 1060-16-0122 | UL 1007 18# | 20 LBS | >20 LBS | Wire damage |
| 1060-16-0122 | UL 1007 16# | 20 LBS | >25 LBS | Grommet broken |
| Terminal Type | Wire Type | Contact Retention | Ref Crimp Tensile | Failure Model |
|---|---|---|---|---|
| 1060-16-0122 | UL 1007 18# | 20 LBS | >20 LBS | Wire damage |
| 1060-16-0122 | UL 1007 16# | 20 LBS | >25 LBS | Grommet broken |
Packaging can be customized to client specifications. Standard lead times:
| Quantity (PCS) | 1 - 1000 | 1001 - 5000 | >5000 | Mold/Tooling |
|---|---|---|---|---|
| Est. Time (Days) | 20 | 25 | To be negotiated | 30 days more |
International shipping available via DHL, UPS, FedEx, TNT, ARAMEX, and EMS. Options for air, sea, or other shipping methods.
