Double Click-In 24V LED Flat Cable Connector
Product Details:
| Place of Origin: | China |
| Brand Name: | Ddgarcn |
| Certification: | CE / ISO9001 |
| Model Number: | Automotive Wiring Harness |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiation |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Negotiation |
| Delivery Time: | Negotiation |
| Payment Terms: | T/T |
|
Detail Information |
|||
| Application: | LED Strip Lighting | Key Features: | Compatible With 2-wire Flat Cables |
|---|---|---|---|
| Length: | Customized Length | Size: | OEM-Wiring Harness |
| Logo: | OEM | Feature: | Optional Custom Cable Lengths |
Product Description
PRS Standard Click-In Design EDG-985 PRS Click-In No Crimping Plug For Truck Tail Light Wiring Connections
Product Overview:
This tool-free double click-in connector is designed for 24V LED lighting systems using flat ribbon cables. It allows fast and secure power connection for LED strips and panels without the need for crimping or soldering.
Key Features:
· Double click-in design for quick install
· Compatible with 2-wire flat cables
· Rated for 24V DC LED lighting systems
· No crimping or soldering required
· Polarized design to prevent reverse connection
· Current rating: Up to 5A
· Operating temperature: -20°C to +80°C
· Optional custom cable lengths
Production Process:
1. Connector tooling and housing assembly
2. Flat cable preparation and alignment
3. Click-in connection and lock check
4. Electrical testing for continuity
5. Labeling and packing
6. Final inspection under IPC standards
Applications:
· LED strip lighting
· Cabinet and furniture LED lighting
· Architectural lighting systems
· Commercial display and signage
Company Advantages - EdgarWireHarness:
· ✅ Over 20 years in LED cable and harness manufacturing
· ✅ Custom tool-free connector design
· ✅ ISO9001 and UL certified
· ✅ Fast sampling and flexible order quantities
· ✅ Complete LED cable solutions with flat cable integration
