Red Automotive Wiring Harness J1939 9 Pin Deutsch To Obd2 Cable For Truck
Product Details:
Place of Origin: | DongGuan in China |
Brand Name: | Edgarcn |
Certification: | UL , CSA , IATF16949 , CE , ROHS |
Model Number: | J1939 & J1962 |
Payment & Shipping Terms:
Minimum Order Quantity: | 3000 |
---|---|
Price: | negotiate |
Packaging Details: | carton size 45*35*25CM |
Delivery Time: | 10-15 days |
Payment Terms: | T/T, L/C, |
Supply Ability: | 10000000 per month |
Detail Information |
|||
Type: | J1939 & J1962 | Length: | Customized |
---|---|---|---|
Certification: | IATF16949 TS16949 UL | Application: | Automobile |
Name: | Automotive Wiring Harness | Color: | Red Molding |
Highlight: | car wiring harness,auto wiring harness |
Product Description
The EDG-HD series is an environmentally silicone rubber sealed, thermoplastic cylindrical connector, which is designed to be a faster, easier, trouble free assembly diagnostic connector in heavy-duty industry like truck, bus, cross-country vehicle,crane and forklift etc. When mated, the contacts are protected from water, dust, lubricating oils, fuel, road salt, grease, mud and other contaminants encountered.
Product Specification
-
Operating at temperatures -40℃ to +125℃, no Cracking, Chipping or leaking after 20 test cycles from -40℃~+125℃.
-
No unlocking or unmating and exhibits no mechanical or physical damage after sinusoidal vibration levels of 20 G’s at 10 to 2000Hz in each of the three mulually perpendicular planes for 2 hours. Force testing report as below shows
-
IP68 rating, waterproof withstand immersion under 1.2 meter of water for 24 hours.
EDG-HD10-9-1939P-P080
Terminal type | Wire type | CONT. Retention | REF crimp tensile | Failue Model |
1060-16-0122 | UL 1007 18# | 20 LBS | >20 LBS | Wire damage |
1060-16-0122 | UL 1007 16# | 20 LBS | >25 LBS |
Grommet broken |
EDG-HD16-9-1939S-P080
Terminal type | Wire type | CONT. Retention | REF crimp tensile | Failue Model |
1060-16-0122 | UL 1007 18# | 20 LBS | >20 LBS | Wire damage |
1060-16-0122 | UL 1007 16# | 20 LBS | >25 LBS | Grommet broken |
